ENGINE
Engine manufacturer TYM T2300N2
Type Natural aspiration
Gross engine power 48.3 hp | 36 kW
PTO power 35.9 hp | 26.4 kW
Rated engine speed 2600 rpm
No. of cylinders 4
Displacement 139.5 cu. in. | 2286 cc
Air cleaner Single dry
Alternator 12V, 70A
Fuel system IDI

POWERTRAIN
Transmission type Mechanical
No. of speeds F12xR12
Max. traveling speed 14.9 mph | 24 km/h
Brakes Wet disc
Steering Hydrostatic
Clutch Dry single plate

CAPACITIES
Fuel tank 9.0 gal | 34 L
Coolant 6.9 qt | 6.5 L
Crankcase 6.8 qt | 6.4 L
Transmission/Hydraulics system 8.5 gal | 32.2 L
Front axle 8.7 qt | 2.1 L

PTO
PTO type Independent
PTO control Electric/Hydro
PTO rear 540 rpm

HYDRAULIC SYSTEM
Pump type Dual gear pump
Implement flow 7.7 gpm | 29 L/min
Steering flow 4.2 gpm | 16.1 L/min
Total flow 11.9 gpm | 45.1 L/min
Category, 3-point hitch I
Hitch lift capacity 2689.6 lb | 1220 kg
Hitch lift capacity at 24 inches behind link ends 1764 lb | 673 kg
Lift control type Position
No. of standard remote valves 1

DIMENSIONS & WEIGHTS
Overall length with 3-point hitch 131 in. | 3320 mm
Overall width 54.5 in. | 1385 mm
Wheelbase 69.7 in. | 1770 mm
Height to top of ROPS 94.5 in. | 2400 mm
Height to top of cabin -
Min. ground clearance 12.8 in. | 325 mm
Min. turn radius with brakes 106.7 in. | 2710 mm
Min. turn radius without brakes 117.5 in. | 2985 mm
Weight with ROPS 3289 lb | 1492 kg
Weight with cab -

STANDARD TIRES
R1 Agricultural - Front Farm Specialist 8.0-16 NHS TL 6PR
R1 Agricultural - Rear Farm Specialist 12.4-24 NHS TL 6PR
R3 Turf - Front Multi-Trac CS 27x10.5-15 NHS TL 4PR
R3 Turf - Rear 12.5x20
R4 Industrial - Front Trac Chief 10-16.50 NHS TL 6PR
R4 Industrial - Rear Xtra Grip 43x16.00-20 NHS TL 6PR
